Repo Onboarding

As you add a repository, Potpie instantly validates the current parsed status. If parsed graph exists, then potpie uses the existing graph, else the repository is passed to the File Analysis.

​
File Analysis

Every file in the repository is evaluated before parsing action is initiated.
  • Files without meaningful source code, such as images, binaries, or notebooks, are excluded early on to avoid unnecessary processing.
  • Files with recognized source extensions are accepted as valid inputs and forwarded for structured analysis.

​
AST Querying

Each file is parsed into an abstract syntax tree and queried for symbols, which are extracted by matching the file against the language grammar.
  • Every function, class, method, or interface discovered is recorded with its exact name and precise location in the codebase.
  • Each symbol is also classified to indicate whether it represents an original definition or a reference to a definition elsewhere.

​
Graph Construction

  • Definitions are represented as nodes in the knowledge graph.
  • References between symbols are represented as edges.
This creates a navigable structural map of the codebase that captures not only what exists, but also interdependency between the components.

​
Storage

  • The repository is marked as ready only when all nodes & relationships are persisted.
  • Any subsequent request for the same commit skips parsing entirely and queries the existing graph directly.
